Schneider LC1G3304KUEN TeSys Contactor
₨424,000.00
The latest Schneider LC1G3304KUEN TeSys Contactor price in Pakistan is Rs. 424,000/- updated on July 23, 2026.
Product Details:
- TeSys Giga high power contactor, 4 poles (4 NO) for category AC-1 applications up to 440A @440V. It provides a 100-250V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 290mm x 185mm x 209mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data.
Features:
- Designed to meet needs of demanding applications built-in with advanced features and functionalities
- Fewer references covering wider applications means simpler to select and less inventory to carry
- Coil designed for less energy consumption and wider voltage band-width
- Modular design and compact size for easy maintenance, short down times and less installation space consumption
- IEC 60335 certificates by authorized agency
HARDWARE FEATURES
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 UL 60335-1 UL 60335-2-40:Annex JJ |
TECHNICAL SPECIFICATION
| Operational Current | 330 A (at <60°C) at <= 440 V AC-3 440 A (at <40°C) at <= 1000 V AC-1 |
| Operational Voltage | <= 1000 V AC 50/60 Hz <= 460 V DC |
| Thermal Current | 440 A (at 40°C) |
| Withstand Current | 2.65 kA – 10 s 1.8 kA – 30 s 1.3 kA – 1 min 0.9 kA – 3 min 0.75 kA – 10 min |
| Withstand voltage | 8 kV |
General Specification
| Circuit voltage | 100…250 V AC 50/60 Hz 100…250 V DC |
| Depth | 226 mm |
| Fuse Rating | 400 A aM at <= 440 V for motor 250 A aM at <= 690 V for motor 500 A gG at <= 690 V |
| Height | 225 mm |
| Mechanical Durability | 8 Mcycles |
| Poles Description | 4P |
| Terminal | Power circuit: bar 2 – busbar cross section: 32 x 10 mm Power circuit: lugs-ring terminals 1 185 mm² Control circuit: push-in 1 0.2…2.5 mm² – cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.25…2.5 mm² – cable stiffness: flexible with cable end Control circuit: push-in 2 0.5…1.0 mm² with cable end Control circuit: push-in 0.75…2.5 mm² – cable stiffness: solid stranded without cable end Control circuit: push-in 0.75…2.5 mm² – cable stiffness: flexible with cable end |
| Weight | 8.3 kg |
| Width | 185 mm |
