Lovato Electric DCRG8 8 Steps Power Factor Controller

The latest Lovato Electric DCRG8 8 Steps Power Factor Controller price in Pakistan is Rs. 425,000/- updated on June 24, 2026.

OVERVIEW:

• Automatic Power Factor Controllers DCRG Series With Graphic Backlit LCD.

Features:

• Suitable for LV-MV systems.
• Display page for V (L-N, L-L), A, KW, KVAR, KWH, KVAh, Temperature, FAN status.
• Harmonic analysis of current and voltage wave forms recorded for overload events.
• TRMS Voltage & Current measurements.
• Auxiliary Power Supply: 100 – 415VAC.
• Connection in single and three phase lines and co-generation system with 4-quadrants operations.
• Current input : Single phasewith 1A or 5A configurable.
• Voltage measurements range : 05-720VAC, Current measurement range : 0.025-1.2A for 1A full scale; 0.025-6A for 5A full scale.
• Back light graphic 128 x 80 pixel LCD with text in multiple languages.
• Display Cos Phi (Current value, Set point Neede value).
• Reliabbility, Capability of working in critical operating conditions and all this to protect Power Factor correction system.
• Reactive power measurement per installed step.
• Capacitor over current protection on all three phases.
• Automatic identification of sense of CT current flow.
• Extreme reduction of the number of switching operations.
• Balanced use of steps with same power rating.
• Capability to correctly operate also in system having high Harmonic content.
• Password protected.
• USB & Wifi compatible.
• IEC degree of protection: IP54 on front; IP20 at terminals.
• Software: DCRJ SW for use with cable 51 C11 for setup and automatic test software is optional and available on request.
