OVERVIEW:
- Lutron CP-3000 Digital Clamp Meter is one of the gauges that can provide an ease of measurement or evaluation of the electric current without disrupting the electrical circuit. When working on the measurement of electric current, and if using a multimeter, we must cut the cable or must disconnect it and connect the measuring device to the circuit to be measured. If you use a clamp meter or tang amperes, then you can judge the current by simply clamping it on one of the wires or on the conductor.
- Clamp Meter Digital Lutron CP-3000 is a device that can be used in measurements or evaluations in the technical world, or for those of you who need an evaluation of the current in your power cord, this one gauge will be very suitable for you. Flexible measuring instruments will be easier to operate. This gauge has a high level of accuracy, so the measurement work will be satisfactory for a user of this meter.
Features:
- Range: 30A / 300A / 3000A
- Output sensitivity: 100mV/A, 10mV/A, 1mV/A
- Output voltage: 3ACV (30A, 300A, 3000A)
- Flexible probe length: 610mm (24 inch)
- Optional current probe for DW-6093, DW-6095
- When change the new probe, the calibration procedures are not necessary
- Output cable: 4 meters wire, used the banana plugs, durable and safety
- Power supply is from the meter, battery is no necessary
Documents:
Summary
| Safety Standard | IEC 1010, Categories III 600V |
| Range | 30A/300A/3000A |
| Weight | 480 g ( 1.06 LB ). |
General Specification
| Accuracy | ± 1% of range value * Accuracy is specified that the measured conductor’s position is on the center of ‘ Flexible current probe ‘. 50/60 Hz.. 23 ± 5 ℃ |
| For | Suitable for DW-6093 & DW-6095 |
| Frequency Range | 45 to 400 Hz Accuracy tested under 50/60 Hz |
| Load | Min : 100 K ohm for specified accuracy. |
| Measurement Range | 30 A/300 A/3000 A, 3 ranges, switch selectable | 1st range value : 30 A | 2nd range value : 300 A | 3rd range value : 3000 A |
| Operating Humidity | Less than 80% RH. |
| Operating Temperature | 0 to 50 ( 32 to 122 ). |
| Output | 100mV/A, 10mV/A, 1mV/A |
| Output Sensitivity | 100 mV/A, 10 mV/A, 1 mV/A, AC coupled. |
| Probe | Flexible Dia : 150mm (6 inch) |
| Power Supply | Power supply is from the meter (DW-6093, DW-6095 ), battery is not necessary. Power supply voltage from DW-6093, DW-6095 is DC 8V± 1V.. |
| Dimension | Main circuit unit : 105 x 56.5 x 33 mm. ( 4.1 x 2.2 x 1.3 inch ). | Flexible probe : 600 mm x 14.5 mm DIA. 23.6 inch x 0.57 inch DIA. | Cable length : 3.4 meters ( 11.2 feet ). | DC plug size : 5.5 mm x 2.5 mm DIA |
