Omron G3FD-X03SN-VD DC5-24 – Solid State Relays
₨ 3,200
The latest Omron G3FD-X03SN-VD DC5-24 - Solid State Relays price in Pakistan is Rs. 3,200/- updated on October 30, 2026.
Product Details:
- The Omron G3FD-X03SN-VD DC5-24 is a DC-switching, single-pole solid-state relay (SSR). The relay is designed for use in a plug-in socket, is compatible in size with Omron’s MY series of relays, and features a built-in operation indicator.
Features:
- Control Voltage Range 4 VDC to 28 VDC (Rated: 5 to 24 VDC)
- Input Impedance 1.5 kΩ (+20% -10%)
- Isolation Method Photocoupler
- Load Current 0.1 A to 3 A (at 40°C)
- Rated Load Voltage 4 VDC to 48 VDC
- Load Voltage Range 3 VDC to 52.8 VDC
- Inrush Current Resistivity 18 A (for 10 ms)
- Output Type DC
Summary
| Voltage range | 3 VDC to 52.8 VDC |
HARDWARE FEATURES
| Input Impedance | 1.5 kΩ (+20% -10%) |
General Specification
| Isolation Method | Photocoupler |
| Load Current | 0.1 A to 3 A (at 40°C) |
| Operate time | 0.5 ms max. |
| Output Type | DC |
| Release time | 2 ms max. |
| Voltage | 4 VDC to 48 VDC |
