The latest Dongjin 2.4kWh Power Wall Lithium Battery 24V 100AH price in Pakistan is Rs. 160,650/- updated on June 13, 2026.
Product Details:
‘Dong Jin’ primarily manufactures 24V wall-mounted lithium-ion batteries for energy storage systems, rather than AC-to-DC power adapters. These are designed for solar, backup power, and telecommunication applications.
Features:
Capacity: This is a 100Ah battery with 2920Wh (2.92 kWh) of energy output.
Design: It features a space-saving, wall-mounted design.
Life Cycle: It boasts a high cycle life of over 5000 cycles at 80% Depth of Discharge (DOD).
Safety Features: The battery includes a built-in protection circuit (BMS) for over-charge, over-discharge, and over-temperature protection.
Communication: Optional communication interfaces like RS485/RS232/CAN are available to integrate with leading inverter brands.
Environmental Tolerance: It is designed to be suitable for a wide range of ambient temperatures, operating from 0°C to 45°C during charging and -20°C to 60°C during discharge.
Protection Class: It has an IP32 protection class.
Weight: The approximate weight is 25 kg.
Summary
| communication interface | Optional RS485/RS232/CAN ports, some models include WiFi and Bluetooth |
TECHNICAL SPECIFICATION
| Nominal voltage | 25.6V |
General Specification
| Battery Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Battery Energy | 2560Wh (2.56kWh) or 2920Wh (3kW version) |
| Cycle Life | Over 5000 to 6000 cycles at 80% Depth of Discharge (DOD) |
| discharge current | 100A |
| Nominal Capacity | 100Ah |
| Operating Temperature | Charge: 0°C to 45°C; Discharge: -20°C to 60°C |
| Protection | IP32 |
| Weight | 25 kg |
| Dimensions | 495mm x 315mm x 170mm |
