Schneider LRD21 TeSys LRD Overload Relays
, ,

Schneider LRD21 TeSys LRD Overload Relays

Compare

₨ 3,640

The latest Schneider LRD21 TeSys LRD Overload Relays price in Pakistan is Rs. 3,640/- updated on October 25, 2026.

OVERVIEW:
Product Compatibilities:

  • LC1D09
  • LC1D12
  • LC1D18
  • LC1D25
  • LC1D32
  • LC1D38
Documents:

Schneider LRD21 TeSys LRD Overload Relays Data Sheet.pdf

Summary

RangeTeSys

HARDWARE FEATURES

Depth70 mm
Mounting SupportPlate with specific accessories.
Rail with specific accessories.
Under contactor
Network TypeDC
AC

Type

product or component typeDifferential thermal overload relay

General Specification

Control TypeRed push-button stop
Blue push-button for reset mode
Network Frequency0…400 Hz
Tightening TorqueControl circuit : 1.7 N.m on screw clamp terminals
Power circuit : 1.7 N.m on screw clamp terminals
weight0.124 kg
Width45 mm
[Ue] Rated Operational Voltage690 V AC 0…400 Hz
[Uimp] rated impulse withstand voltage6 kV
[Ui] rated insulation voltage600 V power circuit conforming to CSA
600 V power circuit conforming to UL
690 V power circuit conforming to IEC 60947-4-1
Adjustable detection range12…18 A
