Industrial Automation & Circuit Protection, Industrial Relays, SCHNEIDER ELECTRIC
Schneider TeSys D Control Relay CAD32
₨ 6,270
The latest Schneider TeSys D Control Relay CAD32 price in Pakistan is Rs. 6,270/- updated on October 28, 2026.
You can buy the Schneider TeSys D Control Relay CAD32 online at Roshanex in Pakistan.
OVERVIEW:
- [Uc] control circuit voltage:
- 48 V AC 50/60 Hz
- 220 V AC 50/60 Hz
- 230 V AC 50/60 Hz
Documents:
Summary
| Height | 77 mm |
HARDWARE FEATURES
| Auxiliary Contact Composition | 3 NO + 2 NC |
| Depth | 84 mm |
| IP degree of protection | IP2x conforming to VDE 0106 |
| Weight | 0.58 kg |
Type
| product or component type | Control relay |
General Specification
| Mechanical Durability | 30 Mcycles |
| Poles Description | 3P |
| Tightening Torque | 1.2 N.m – on screw clamp terminals – with screwdriver Philips No 2 1.2 N.m – on screw clamp terminals – with screwdriver flat Ø 6 mm |
| Width | 45 mm |
| [Uc] control circuit voltage | 24 V AC 50/60 Hz |
| [Ue] Rated Operational Voltage | <= 690 V AC 25…400 Hz |
