The latest Uni-T UT207B True RMS Digital Clamp Meter price in Pakistan is Rs. 17,400/- updated on June 24, 2026.
OVERVIEW:
- UT200 series are 6000-count digital clamp meters with auto-range, large LCD, true RMS, autoscale memory, and NCV functions. They conform to CAT III 1000V/CAT IV 600V safety rating andcertified by CE/ETL. The UT206B, UT207B, and UT208B come with LoZ mode for eliminating ‘ghost ‘voltage, LPF ACV function for measuring INV and VFD voltage, and inrush current mode for capturing transient current. The UT206B and UT208B also feature high-precision temperature measurements with 0.1°C resolution and can be equipped with a flexible current probe to extend the AC current measurement range to 3000A.
Features:
- Flashlight button: Short press this button to turn on/off the flashlight.
- Flexible current probe (optional) to extend the AC current measurement range to3000A
- Inrush current capture
- NCV Multi-Segment Display and audio/visual alarm
- True RMS/Auto backlight
- NCV/Function retention
Current AC
| AC Voltage | 6V ±(1.2%+3) 60V/600V/1000V ±(1%+8) |
Display Specification
| Color | Red and grey |
| Display | 43mm x 45mm |
Summary
| Duty Cycle | 10%~90% ±(2.6%+7) |
Antenna
| Capacitance | 60nF ±(4%+25) 600nF/6μF/60μF/600μF ±(4%+5) 6mF/60mF ±(10%+9) |
TECHNICAL SPECIFICATION
| Power | 1.5V battery (R03) |
General Specification
| AC Current range | 1000A |
| Display count | 6000 |
| Frequency | 50Hz~60Hz |
| Resistance | 600Ω ±(1%+3) 6KΩ/60KΩ/600KΩ ±(1%+2) 6MΩ/60MΩ ±(2%+8) |
| Type | True RMS Digital Clamp Meter |
