Earth & Insulation Tester, Industrial Meter, Kyoritsu
Kyoritsu 3007A Digital Insulation / Continuity Testers
₨65,000.00
The latest Kyoritsu 3007A Digital Insulation / Continuity Testers price in Pakistan is Rs. 65,000/- updated on August 31, 2026.
FEATURES:
- Bargraph to display insulation resistance.
- Displays the value of external AC voltage along with the flashing symbol.
- Auto null function to automatically subtract the test lead resistance before displaying the real continuity resistance value.
- Trac-Lok mode to conserve battery life on insulation and continuity tests.
- Live circuit warning beeper.
- Releasing the test button automatically discharges the charges stored in the circuit under test.
- Backlight function to view the test results in dimly lit areas.
- 200mA continuity measuring current to IEC 61557.
- Minimum 1mA current on insulation tests to IEC 61557.
Documents:
Kyoritsu 3007A Digital Insulation / Continuity Testers Data Sheet.pdf
Summary
| EMC Standard | IEC 61326-1 |
| Included Accessories | 7122B (Test leads) Pouch for test leads 8923 (F500mA/600V fuse) × 2 R6 (AA) × 8 Shoulder Strap Instruction Manual |
| Nominal current | (Insulation Resistance) 1mA DC min. |
| Output short circuit current | (Insulation Resistance) 1.5 mA DC approx. |
| Safety Standard | EC 61010-1 CAT III 300V Pollution Degree 2 IEC 61010-2-031 IEC 61557-1/2/4 |
| AC Voltage | (AC Voltage) 0-600V AC |
| Accuracy | (Continuity Test) ±1.5%rdg±5dgt (20Ω) ±1.5%rdg±3dgt (200Ω/2000Ω) (Insulation Resistance) ±1.5%rdg±5dgt (20MΩ/200MΩ) ±10%rdg±3dgt (2000MΩ) (AC Voltage) ±5%rdg±3dgt |
| Measuring range | (Continuity Test) 20Ω/200Ω/2000Ω (Mid-scale value) (Insulation Resistance) 20MΩ/200MΩ/2000MΩ |
| Weight | 990g approx |
| Measuring Current | (Continuity Test) 200mA DC min. |
| Test Voltage | (Insulation Resistance) 250V/500V/1000V |
| Output Voltage on Open Circuit | (Continuity Test) 7 – 12V DC (Insulation Resistance) 1.5 mA DC approx. |
| Power Source | R6 (AA) (1.5V) × 8 |
TECHNICAL SPECIFICATION
| IP Rating | IEC 60529-IP54 |
General Specification
| Dimensions | 167(L) × 185(W) × 89(D)mm |
