The latest Kyoritsu KT203 Digital AC/DC Clamp Meter price in Pakistan is Rs. 21,000/- updated on August 30, 2026.
FEATURES:
- Safety design conforming to IEC61010
- Protected throughout by double or reinforced insulation, indicated the International Electrical Symbol on the bottom of the instrument
- Data hold switch for easy reading in dimly lights or hard-to-read locations
- Sleep feature to extend battery life
- Beeper permits easy continuity check
- Provides a dynamic range of 4000 counts full scale
Documents:
Display Specification
| Display | LCD 3,75 digit 13mm |
TECHNICAL SPECIFICATION
| AC Current Measuring Range | 10mA…40A/400A |
| DC Current Measuring Range | 10mA…40A/400A |
| Resistance Measuring Accuracy | ±(2% + 5 digits) |
| Resistance Measuring Range | 100mΩ…400Ω/4kΩ |
General Specification
| AC current measuring accuracy | ±(3% + 8 digits) |
| AC voltage measuring accuracy | ±(2% + 5 digits) |
| AC voltage measuring range | 100mV…400V/600V |
| Continuity Test | acoustic signal for R<50Ω |
| DC current measuring accuracy | ±(3% + 8 digits) |
| DC voltage measuring accuracy | ±(1,5% + 5 digits) |
| DC voltage measuring range | 100mV…400V/600V |
| Sampling | 2,5x/s |
| Type of meter | AC/DC digital clamp meter |
| Dimensions | 187x69x39mm |
| Power Supply | 2 batteries 1,5V LR03 (AAA) |
